High-Precision Optical Profile Projector
What is a Profile Projector?
A Profile Projector is a high-precision measuring instrument that integrates optical, mechanical, and electronic technologies. It projects the actual contour of a workpiece onto a screen, enabling non-contact measurement and allowing precise inspection of dimensions, shapes, surface profiles, and fine features.
Modern profile projectors combine digital measurement with traditional projection functions. They can be operated via mouse, keyboard, or touchscreen, and work in conjunction with professional measurement software to perform automated measurements and data recording. This significantly improves inspection efficiency and accuracy. Profile projectors are widely used in research, education, calibration laboratories, and production quality control, making them an indispensable tool in modern manufacturing.
Key Advantages of Profile Projectors
High-Precision Measurement - Coordinate measurement error can reach (3+L/200)µm, and contour measurement error is less than 0.08%, meeting the strict inspection requirements of precision components and tools.
Fast and Efficient Inspection - Capable of quickly measuring various complex workpieces, including templates, stamped parts, cams, gears, threads, form cutters, tools, and precision components.
Robust Load-Bearing and Durable Design - Z-axis or projection tube lifting design allows the instrument to support heavier workpieces without compromising measurement accuracy, ensuring long-term stability.
Multi-Format Data Output - Measurement results can be exported in TXT, Excel, and other formats. Optional mini printers and foot switches enhance data collection and recording efficiency.
Versatile Applications - Suitable for measuring terminals, watch components, diamond parts, and various tools, molds, and hardware, making it an ideal supplement for areas that are difficult for vertical projectors to inspect.
Application Range
Profile projectors are widely used in:
Mechanical manufacturing and processing, Mold design and inspection, Instrumentation and electronic component testing, Hardware and precision plastic parts production, Precision terminals, watch parts, and diamond parts manufacturing, Education, research, and calibration laboratories.
They are suitable for both production workshops and metrology rooms, providing high-precision quality control and accurate contour measurement for complex parts.
Customization Support
To meet diverse customer needs, we offer flexible customization options, including:
Functionality and performance optimization, Interface and software design tailored to workflow requirements, Special configurations for unique measurement tasks.
Through customized solutions, profile projectors can be adapted to different production processes and workpiece characteristics, improving measurement efficiency and precision and providing comprehensive solutions for customers.
